Description / type | 16,5 cm / 6,5″ single stereo coaxial speaker |
Impedance | 2 x 4 ohm dual voice coil |
Sensitivity | 90 dB (1W/1m) |
Frequency range | 50 – 18 000 Hz |
Recommended amplifier | 20-120 Watt |
Tweeter | 2 x 16 mm / 0,83″ mylar tweeter |
Woofer size | 16,5 cm (6,5″) |
Outer dimensions | 228 mm / 8,98″ |
Cutout dimensions | 192 mm / 7,56″ |
Mounting depth | 75 mm / 3″ |
Baffle thickness | 10-33 mm |
Off-axis angle | +- 45 degrees in distributed audio systems |
Finish / colour | White |
Weight | 1,6 kg / 3,52 lbs |
