| Description / type | 2-way coaxial for ceiling mount |
| Impedance | 4 ohm |
| Sensitivity | 90 dB (1W/1m) |
| Frequency range | 50 – 20 000 Hz |
| Recommended amplifier | 20 – 100Watt |
| Tweeter | 20 mm soft dome |
| Woofer size | 6,5″ (165 mm) |
| Outer dimensions | 234 mm (9,21″) |
| Cutout dimensions | 205 mm / 8,07″ |
| Mounting depth | 65 mm / 2,56″ |
| Baffle thickness | 10-33 mm |
| Off-axis angle | +- 45 degrees in distributed audio systems |
| Weight | 1,5 kg / 3,3 lbs |
| Finish / colour | White |
Specifications
Description / type 2-way coaxial for ceiling mount
Impedance 4 ohm
Sensitivity 90 dB (1W/1m)
Frequency range 50 – 20 000 Hz
Recommended amplifier 20 – 100 Watt
Tweeter 20 mm soft dome
Woofer size 6,5″ (165 mm)
Cone material Polypropylene with rubber surround
Outer dimensions 234 mm (9,21″)
Cutout dimensions 205 mm / 8,07″
Mounting depth 65 mm / 2,56″
Baffle thickness 10-33 mm
Off-axis angle +- 45 degrees in distributed audio systems
Weight 1,5 kg / 3,3 lbs
Finish / colour White, RAL 9003
EAN Bar code 7331644625100
Article number(s)
IC-IC623
