CA31 is a three channel amplifier with a nominal output of 2 x 65 Watts + 1 x 170 Watts (1 x 280 Watts in 2 ohm).
- Built-in high-pass, low-pass and subsonic filters.
- Protection circuits shut down the amplifier in the event of overloads.
- Phase shift control on sub channel
- High level input with auto start.
- The perfect amplifier for a standard installation with a front system in stereo and a subwoofer in the back.
- RMS output power @ 13,8 V, 20Hz – 20 kHz
| Number of channels | 3 |
| Amplifier class | AB |
| Output power in 2 ohm | 2 x 90 W RMS |
| Output power in 4 ohm | 2 x 65 W RMS |
| Mono sub channel 2 ohm | 280 W |
| Mono sub channel 4 ohm | 170 W RMS |
| Damping factor | >100 |
| S/N ratio, A-weighted | >100 dB |
| Frequency range | 10 Hz – 35 kHz |
| Input sensitivity | 0,25 – 5 V |
| Input impedance | >10 kohm |
| Input impedance, high level | 100 ohm |
| Filters channel A & B | HP: 50-150 Hz |
| Remote bass level control | No |
| Filter sub channel | Lowpass: 50 – 120 Hz + subsonic 25 Hz |
| Low level output | No |
| Remote phase shift control | No |
| Phase control for subwoofers | 0-180 degrees cont. variable |
| High level input with auto start | Yes |
| Power consumption (idle) | 1A |
| Power consumption (max) | 60A |
| Rec. power cable | Minimum 4AWG / 21 mm2 |
| Fuses | 2 x 30 A |
| Dimension (W x D x H) | 250 x 340 x 67 mm / 9,84 x 13,38 x 2,63″ |
| Weight | 4,2 kg ( 8,9 lb) |
