| Number of channels | 1 |
| Amplifier class | AB |
| Output power in 2 ohm | 265 W RMS |
| Output power in 4 ohm | 180 W RMS |
| Frequency range | 25-160 Hz |
| Input sensitivity | 0,2-7 V |
| Input impedance | 10 kohm |
| Input impedance, high level | 300 ohm |
| Low pass filter | 35 – 100 Hz, 24 dB slope |
| High pass filter | Subsonic 25 Hz |
| Phase control for subwoofers | 0/180 + 0 – 90 degrees variable |
| Low level output | No |
| High level input with auto start | Yes |
| Rec. power cable | Minimum 7AWG / 10 mm2 |
| Remote phase shift control | No |
| Dimension (W x D x H) | 255 x 160 x 66 /10 x 6,3 x 2,6 |
| Remote bass level control | No |
| Weight | 1,4 kg (3,1 lb) |
| Integrated fan | Yes |
| Power consumption (max) | 35 A |
| Fuses | 1 x 35 A |
