Number of channels | 4 |
Amplifier class | AB |
Mono bridge mode 2 ohm | 2 x 400 W RMS |
Mono bridge mode 4 ohm | 2 x 250 W RMS |
Output power in 1 ohm | 4 x 220 W RMS |
Output power in 2 ohm | 4 x 145 W RMS |
Output power in 4 ohm | 4 x 85 W RMS |
Damping factor | > 200 |
S/N ratio, A-weighted | > 100 dB |
Frequency range | 10 Hz – 50 kHz |
Input impedance, high level | N/A |
Input sensitivity | 0,2 – 7 V |
Input impedance | > 10 kohm |
Filters channel A & B | LP: 50-125 Hz. HP: 20-200 Hz / 60-600 Hz |
Remote bass level control | No |
Filters channel C & D | LP: 45-200 Hz / 90-400 Hz. HP: 20-200 Hz |
Low level output | No |
Remote phase shift control | No |
High level input with auto start | No |
Dual DC inputs | Yes |
External cooling fan terminal | Yes |
Power consumption (idle) | 1,5 A |
Power consumption (max) | 95 A |
Dimension (W x D x H) | 465 x 240 x 73 mm (18,30 x 9,45 x 2,87 inches) |
Rec. power cable | Minimum 4AWG / 21 mm2 |
Weight | 6,6 kg ( 14,55 lb) |
