CA 22 is a powerful amplifier with a power output of 2 x 60 Watts. With a mono bridge-connection, it puts out all of 200 Watts.
- Built-inlow-pass filter for subwoofers, variable between 50 and 500 Hz.
- The high-pass filter is variable between 15 and 500 Hz.
- Built-in protection circuits shut down the amplifier in the event of overloads.
- High level input with AUTO-start function makes it easier to connect to factory installed head units.
- RMS output power @ 13,8 V, 20Hz – 20 kHz
| Number of channels | 2 |
| Amplifier class | AB |
| Mono bridge mode 4 ohm | 200 W RMS |
| Output power in 2 ohm | 2 x 100 W RMS |
| Output power in 4 ohm | 2 x 60 W RMS |
| Damping factor | >100 |
| S/N ratio, A-weighted | >100 dB |
| Frequency range | 10 Hz – 35 kHz |
| Input sensitivity | 0,25 – 5 V |
| Input impedance | >10 kohm |
| Input impedance, high level | 100 ohm |
| High pass filter | 15-500 Hz |
| Low pass filter | 50 – 500 Hz |
| Low level output | Yes |
| High level input with auto start | Yes |
| Power consumption (idle) | 0,5 A |
| Power consumption (max) | 25 A |
| Rec. power cable | Minimum 5AWG / 16 mm2 |
| Fuses | 1 x 25 A |
| Dimension (W x D x H) | 250 x 212 x 67 mm / 9,84 x 8,35 x 2,63″ |
| Weight | 2,7 kg / 5,95 lb |
