Number of channels | 2 |
Amplifier class | AB |
Mono bridge mode 4 ohm | 440 W RMS |
Output power in 2 ohm | 2 x 200 W RMS |
Output power in 4 ohm | 2 x 130 W RMS |
Damping factor | > 200 |
S/N ratio, A-weighted | > 100 dB |
Frequency range | 10 Hz – 50 kHz |
Input sensitivity | 0,2 – 7 V |
Input impedance | > 10 kohm |
Input impedance, high level | 330 ohm |
High pass filter | 20 – 150 Hz |
Low pass filter | 40 – 125 Hz |
Grand bass filter | 0-18 dB @ 40 Hz |
Low level output | No |
Phase control for subwoofers | 0-180 degrees cont. variable |
High level input with auto start | Yes |
Power consumption (idle) | 0,6 A |
Power consumption (max) | 50 A |
Rec. power cable | Minimum 4AWG / 21 mm2 |
Fuses | 2 x 25 A |
Dimension (W x D x H) | 359 x 245 x 59 mm (14,1 x 9,65 x 2,33 inch) |
Weight | 3,8 kg ( 8,4 lb) |
